Revell 1/32 ARADO 196 with extras

[shepard]

Hi again Jayl, now with the pics i know exactly what you mean... im trying to do the same, but without moving the front leg...will see.. if not possible i will do the same way you did... excelent job...

Tks again for your tip and help...

Hope you like my work here....



Shep

[shepard]

Another question for you my friends .... fabric surfaces (screened) received no apparent rivets? Wings have such detail or not?



if you guys can help me i apreciate...



tks in advance



Shep

[shepard]

well..as i had a bump with my last question.. things have to go on....



now im working on the IP and other canopy stuff..



I change some parts as advised...



soon will post some pics..



cheers



Shep

[shepard]

So.. here we go my friends.. a little update as i promised...





















For now, just base color ( primed black) and faded with vallejo light gray green...



will ad some washes and weathering stuff...

[shepard]

here the ARADO IP..... need to paint red one of the "rings"....hope you guys like...





























[necron99]

Very nice, Very very nice !



I'm getting ready to start my Ar 196 soon, and your build is just that nice it's inspiring.



I did notice and have been thinking long and hard about the Eduard instrument panel. The newer pre painted ones just don't have that realistic "glass face dial look" Which is why you went with the Krystal Kleer. I was thinking the same thing and you confirmed it. I kinda wish that Eduard would go back to the film instruments...



Hey a real quicky if ya don't mind. Do you know what the actual colors used in the cockpit were ? (I don't like the Eduards RLM 66 look alike color) Every thing I've seen seems to say RLM 02, Also would the colors change say after a 1942 repaint ? (like over to RLM66) I might wind up trying the kit instrument panels with Kagero instrument decals, or try and repaint the Eduard ones.

TIA :-)



Thanx for sharing !!



Allan

[shepard]

Hi Allan ... greetings from Brazil to you my friend. im glad that you are liking it.

About the RLM colors, you are right, and im about to do some shades of my RLM 02.

Luftwaffe cockpits were, RLM 02, a light green with shades of medium gray, or RLM 66, a darker gray. Later, RLM 66 became the standard color. RLM 02 on early war cockpits of lufts aircraft. Some bigger bombers tended to be RLM 66 more often.

BTW. the eduard pre painted p.es. didnt glues well when you prime de kit part.... you must let them free of paint and well clean...if you want stuck them well in place...

You can use FUTURE if you have no Krystal Klear...same tec. toothpick with some layers waiting them to dry...





Shep

Edited September 17, 2012 by shepard

[Jayl]

Looking good Shep.

[shepard]

Looking good Shep.



Tks Jayl, your tip helped me a lot....if you please, continue to comment here i apreciate



Shep

[necron99]

Hi Allan ... greetings from Brazil to you my friend. im glad that you are liking it.

About the RLM colors, you are right, and im about to do some shades of my RLM 02.

Luftwaffe cockpits were, RLM 02, a light green with shades of medium gray, or RLM 66, a darker gray. Later, RLM 66 became the standard color. RLM 02 on early war cockpits of lufts aircraft. Some bigger bombers tended to be RLM 66 more often.

BTW. the eduard pre painted p.es. didnt glues well when you prime de kit part.... you must let them free of paint and well clean...if you want stuck them well in place...

You can use FUTURE if you have no Krystal Klear...same tec. toothpick with some layers waiting them to dry...





Shep







Hi Shep. (and big Hello from Virginia USA)



Thanx for responding !



I'm slowly grinding through a 1/48 TBD-1 but am researching for my upcomming AR 196 build. Reason I'm asking questions and following every Ar 196 build here. And your's is going to really be something when done !

I got the Eduard Big Ed set, Master Models Mg barrels, and the Quickboost exhaust.. After the cockpit the only thing that bothers me is the stupid canopy. I'll figure that one out later...



Thanks again

Allan

[shepard]

Hi Allan... again, you are 100% right... im avoiding talk about the canopy....

It will be a real challenge thats for sure... lets wait a little bit more...if you know what i mean...



Why doesnt anyone of the aftermarket god´s made vacform ones or something that helps us???



Revell.. in the name of "budget" made them so tricky that will be a test of my average skills...



tks again for your comment my friend



Shep

[shepard]

Hi there... a quick question for you guys... fuel lines goes to and fuel tank are located on the floats?

And somebody has a pic of the internal structs after the rear machine gun?



The fuselage, has two plates one on the side and one on the top that are not fabric ones... what we have inside them??



im thinking to go to the kagero arado top drawing one what do you guys think?



some help will be very apreciated



tks in advance



Shep

[miamiangler]

The top drawing book only gives exterior drawings nothing interior except dashboard . Has some nice decals





The book you want is Ar 196 #45 3045 from the same company Kagrero. gives the interior truss layout which Revell got all wrong and float layout s of the different variants.



The compartment on top in the rear is for the main Compass (mother compass).



Willi

Edited September 17, 2012 by miamiangler

[shepard]

Thanks Willi... do you have any pics of this " mother compass", can be in other ww2 plane if you please..



Shep

[Guest]

Very nice work ! I like it. Keep posting !........Harv
