1/43rd scale DH Hornet Moth scratchbuild.


  • Please log in to reply
33 replies to this topic

#16 GuildAero

GuildAero

    Senior Member

  • LSP_Members
  • PipPipPipPipPipPip
  • 608 posts
  • Gender:Male
  • Location:East Anglia

Posted 18 July 2017 - 08:30 AM

Marus, Jim, many thanks for your kind words and interest.



It is a pretty bird, especially in that lovely green livery.



BTW, I hadn't noticed that I had two identical pics., so I changed the lower for what it should have been!



Cheers,

Martin


Manifestly it is better to use simple tools expertly than to possess a bewildering assortment of complicated gadgets and either neglect or use them incompetently. ( L.T.C.Rolt)

Artwork at :- http://drawingboard.....com/index.html

Blog at:-      http://oddsoracle.blogspot.co.uk/


#17 Gazzas

Gazzas

    Senior Member

  • LSP_Members
  • PipPipPipPipPipPip
  • 1,451 posts
  • Gender:Male
  • Location:Queensland, Australia

Posted 18 July 2017 - 08:42 AM

I'm liking seeing this thing grow!



Nice work!



Gaz


​We don't have social skills.  We build models.


#18 GuildAero

GuildAero

    Senior Member

  • LSP_Members
  • PipPipPipPipPipPip
  • 608 posts
  • Gender:Male
  • Location:East Anglia

Posted 18 July 2017 - 09:58 AM

Thanks, Gaz.  Not much happening today as visitors coming soon.



Martin


Manifestly it is better to use simple tools expertly than to possess a bewildering assortment of complicated gadgets and either neglect or use them incompetently. ( L.T.C.Rolt)

Artwork at :- http://drawingboard.....com/index.html

Blog at:-      http://oddsoracle.blogspot.co.uk/


#19 GuildAero

GuildAero

    Senior Member

  • LSP_Members
  • PipPipPipPipPipPip
  • 608 posts
  • Gender:Male
  • Location:East Anglia

Posted 19 July 2017 - 02:15 PM

Here we have the tailplane and elevators made in 60 thou. styrene sheet.  The elevators are glued on to the tailplane halves with solvent glue at a slight droop, for interest.  There are no hints at hinges because the fabric is doped right across the joint twixt tailplane and elevators as is usual with De Havillands, including the much larger Dragon Rapide.  Underneath there is a wedge shaped gap to allow for down elevator, but up elevator just slightly wrinkles the fabric.

There's a hole right through the fin which allows access to the horn that operated the elevators, the halves of which are joined with a metal bar.  The fronts of the tailplane halves are fitted in holes in the fuselage fairing shape.  These are rods of brass wire of 0.8mm diameter. The holes are drilled by hand using a pin chuck.  In the photograph it is all held mechanically, prior to detailing the surfaces and gluing them in.  As these flying surfaces are different colours from the main colour they will be painted separately and attached last thing, along with the relevant straining wires.


The wire joiners in place.




Cheers,

Martin


  • 109, mustang1989, Girlscanplay2 and 1 other like this

Manifestly it is better to use simple tools expertly than to possess a bewildering assortment of complicated gadgets and either neglect or use them incompetently. ( L.T.C.Rolt)

Artwork at :- http://drawingboard.....com/index.html

Blog at:-      http://oddsoracle.blogspot.co.uk/


#20 ClumsyDude

ClumsyDude

    Senior Member

  • LSP_Members
  • PipPipPipPipPipPip
  • 3,012 posts
  • Gender:Male
  • Location:Sydney

Posted 19 July 2017 - 03:03 PM

Wow, Martin, this is looking really amazing. Great work!

Jim

#21 GuildAero

GuildAero

    Senior Member

  • LSP_Members
  • PipPipPipPipPipPip
  • 608 posts
  • Gender:Male
  • Location:East Anglia

Posted 19 July 2017 - 05:17 PM

Thanks, Jim.



More pics later tonight of the ribbbing "skins" laid over the styrene cores.  And the cockpit painted.



Martin


Manifestly it is better to use simple tools expertly than to possess a bewildering assortment of complicated gadgets and either neglect or use them incompetently. ( L.T.C.Rolt)

Artwork at :- http://drawingboard.....com/index.html

Blog at:-      http://oddsoracle.blogspot.co.uk/


#22 MostlyRacers

MostlyRacers

    Senior Member

  • LSP_Members
  • PipPipPipPipPipPip
  • 4,981 posts
  • Gender:Male
  • Location:Cornod. French Jura

Posted 19 July 2017 - 09:31 PM

I recognise your magic at work, Martin :bow:

:popcorn:

Hubert

#23 GuildAero

GuildAero

    Senior Member

  • LSP_Members
  • PipPipPipPipPipPip
  • 608 posts
  • Gender:Male
  • Location:East Anglia

Posted 20 July 2017 - 08:20 AM

Thanks Hubert.  Just filling in with something for me while all the slot racers have their "silly season".  I might start doing some paintings again soon once I find my easel.



Cheers,

Martin


Manifestly it is better to use simple tools expertly than to possess a bewildering assortment of complicated gadgets and either neglect or use them incompetently. ( L.T.C.Rolt)

Artwork at :- http://drawingboard.....com/index.html

Blog at:-      http://oddsoracle.blogspot.co.uk/


#24 mustang1989

mustang1989

    Hooked For Life

  • LSP_Members
  • PipPipPipPipPip
  • 280 posts
  • Gender:Male
  • Location:Coastal Bend in Texas

Posted 20 July 2017 - 06:13 PM

Watchin' tha magic show.................... :popcorn:



#25 GuildAero

GuildAero

    Senior Member

  • LSP_Members
  • PipPipPipPipPipPip
  • 608 posts
  • Gender:Male
  • Location:East Anglia

Posted 20 July 2017 - 10:21 PM

Thanks, Mustang.  Should have taken some pics today, but busy making a windscreen pattern from Milliput because I couldn't bend it up from flat sheet.

So, pictures tomorrow.



Martin


Manifestly it is better to use simple tools expertly than to possess a bewildering assortment of complicated gadgets and either neglect or use them incompetently. ( L.T.C.Rolt)

Artwork at :- http://drawingboard.....com/index.html

Blog at:-      http://oddsoracle.blogspot.co.uk/


#26 Old Dog Flying

Old Dog Flying

    Hooked For Life

  • LSP_Members
  • PipPipPipPipPip
  • 468 posts
  • Gender:Male
  • Location:White Rock, BC, Canada

Posted 20 July 2017 - 11:59 PM

Very nice project Martin.  I used the same method on my 1:32 Fleet Canuck..



Barney  www.barneysairforce.com



#27 GuildAero

GuildAero

    Senior Member

  • LSP_Members
  • PipPipPipPipPipPip
  • 608 posts
  • Gender:Male
  • Location:East Anglia

Posted 21 July 2017 - 12:28 PM

I just do what I need to as I go along, Barney, I don't tend to think about it much.



Cheers,

Martin


Manifestly it is better to use simple tools expertly than to possess a bewildering assortment of complicated gadgets and either neglect or use them incompetently. ( L.T.C.Rolt)

Artwork at :- http://drawingboard.....com/index.html

Blog at:-      http://oddsoracle.blogspot.co.uk/


#28 GuildAero

GuildAero

    Senior Member

  • LSP_Members
  • PipPipPipPipPipPip
  • 608 posts
  • Gender:Male
  • Location:East Anglia

Posted 21 July 2017 - 08:17 PM

As promised, photos up to date.  Alas, I have been gardening and researching an English Electric Lightning as my dear wife has ordered me an Airfix 1/48th scale kit, out of the blue.



Anyway, here we have an as yet incomplete Milliput pattern for the windscreen (an absolute bar steward to hold in any direction!)

Tailplane and elevators with rib-impressed 10 thou. skins. Elevators slightly down. I like that look.

Wings started. Roughly shaped with chisels to save on dust production.  One 10 thou skin waiting for rib impression.

Prop. sanding sealered and painted a la real kite at Felthorpe.







More anon.



Martin

I'm off to persuade a little more Milliput on to that pattern, then cook it to harden.


  • MostlyRacers and Girlscanplay2 like this

Manifestly it is better to use simple tools expertly than to possess a bewildering assortment of complicated gadgets and either neglect or use them incompetently. ( L.T.C.Rolt)

Artwork at :- http://drawingboard.....com/index.html

Blog at:-      http://oddsoracle.blogspot.co.uk/


#29 Old Dog Flying

Old Dog Flying

    Hooked For Life

  • LSP_Members
  • PipPipPipPipPip
  • 468 posts
  • Gender:Male
  • Location:White Rock, BC, Canada

Posted 21 July 2017 - 09:27 PM

Here I thought that my "Work-Mate" was in my hangar!!!!!   How did it get to your side of the "Pond" ?



Barney



#30 GuildAero

GuildAero

    Senior Member

  • LSP_Members
  • PipPipPipPipPipPip
  • 608 posts
  • Gender:Male
  • Location:East Anglia

Posted 21 July 2017 - 09:43 PM

Went to buy a mini freezer from a local guy and he offered me this workmate, cheap, which has its legs welded down which means I can move it round outside the shed.  I use it to put the bandsaw or belt sander on so the dust blows away. It lives outdoors.  So useful.  I can only get decent pictures in outside light.  I suppose I should keep a neutral sheet of something for photos, but I ain't a photographer!
